Name: TP-Link TP-Link TL-SG105PE, Managed, L2, Gigabit Ethernet (10/100/1000), Power over Ethernet (PoE)
Brand: TP-Link
SKU: TL-SG105PE
Price: 50.00 EUR
Availability: InStock

Bullets

Managed L2 Web-gebaseerd management
Quality of Service (QoS)
Aantal basis-switching RJ-45 Ethernet-poorten: 5
Cat3, Cat4, Cat5, Cat5e, Cat6 10BASE-T, 100BASE-FX, 100BASE-TX, 1000BASE-T
MAC-adrestabel: 2000 entries Switchingcapaciteit: 10 Gbit/s
DC Vermogenstoevoer inclusief Power over Ethernet (PoE)

Reasons to buy

Technical details
Quality of Service (QoS) support
Flow control support
Auto MDI/MDI-X
Switching capacity	10Gbit/s
MAC address table	2000entries
Packet buffer memory	1MB
Rack mounting
Input current	1.31A
Input voltage	53.5V
Power consumption (max)	75.16W
Power over Ethernet (PoE)
Bedrijfstemperatuur (T-T)	0 - 40°C
Temperatuur bij opslag	-40 - 70°C
Relatieve vochtigheid in bedrijf (V-V)	10 - 90procent
Storage relative humidity (H-H)	5 - 95procent
Heat dissipation	256.3BTU/h
Breedte	99.8mm
Diepte	98mm
Hoogte	25mm
User guide
Package width	131mm
Package depth	196mm
Package height	121mm
Package weight	770g
Switch type	ManagedTekst
Networking standards	IEEE 802.1Q,IEEE 802.1p,IEEE 802.3ab,IEEE 802.3af,IEEE 802.3at,IEEE 802.3i,IEEE 802.3u,IEEE 802.3xTekst
Cable types supported	Cat3,Cat4,Cat5,Cat5e,Cat6Tekst
Kleur van het product	BlackTekst
LED indicators	Activity,Link,PoE,Power,Speed,StatusTekst
Certificering	FCC, CE, RoHSTekst
Power source	DCTekst

Netwerk
Web-based management
10G support
Port mirroring
Link aggregation
Broadcast storm control
Rate limiting
Auto-negotiation
VLAN support
Number of VLANs	4000Tekst
Forwarding rate	7.44Mpps
Store-and-forward
Jumbo frames support
Jumbo frames	16000Tekst
IGMP snooping
Switch layer	L2Tekst
Virtual LAN features	Port-based VLAN,Tagged VLANTekst

Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity	5Tekst
Gigabit Ethernet (copper) ports quantity	5Tekst
Power over Ethernet plus (PoE+) ports quantity	4Tekst
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)Tekst
Copper ethernet cabling technology	10BASE-T,100BASE-FX,100BASE-TX,1000BASE-TTekst

Power
Power supply included
Power over Ethernet (PoE) power per port	30W
Total Power over Ethernet (PoE) budget	65W

Other features
Fanless
Harmonized System (HS) code	85176990Tekst

Data transmission
Number of queues	4Tekst

Security
Loop protection

Kenmerken
Verschijningsdatum	22-07-2020

Show all specificationsShow less
